FSTB wholesale Intelligent Thermostat Electric Gas Oven Capillary Thermostat

FOB Reference Price:Get Latest Price
US $2-3 / Pieces | 500 Piece/Pieces Capillary Thermostat (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Other Home Appliance Parts
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
FSTB
Model Number:
WYG
Product name:
capillary thermostat
Temperature:
Max. 320℃
Tolerance range:
3~12℃
Diff. range:
1~17℃
Insulation resistance:
>100mΩ
Dielectric strength:
2000V. AC 1min
Test gradient:
≤ 1.0℃/min
Rotating torque of adjustment shaf:
<40N.cm
Max ambient temp. of main body:
150℃
Switch type:
SPST / SPDT
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Month Capillary Thermostat
Packaging & Delivery
Packaging Details
100 per carton, the carton size is 408(L)*365(W)*192(H)(mm)
Port
FOSHAN
Lead Time :
15-20 Days

FSTB wholesale Intelligent Thermostat Electric Gas Oven Capillary Thermostat



Product Description

  Thermostat, WYG series, utilizes the ceramic switch box, has the advantages of accurate temperature controlling, wide control range, great contact capacity, high reliabilities and thin thickness. It is suited for electric heater, electric boiler, drum washing machine, electric oven and so on, as electric-thermal control. It is also suited for room temperature control and refrigeration control.





PARAMETERS:



Rated current and rated voltage of switch

  C-1:16(2.5) A 250V~C-2:3(0.5) A 250V

  C-1:25(2.6) A 277V~C-2:3(0.5) A 277V

Control range

  Max.320℃

Tolerance on operating range

  3~12℃

Differential range

  1~17℃

Insulation resistance

  >100MΩ(normal)

Dielectric strength

  2000V. AC 1min (normal)

Life cycles

  >100000(250V)

  >30000(277V)

Test gradient

  ≤1.0℃/min (liquid medium)

Rotating torque of adjustment shaft

  <40N.cm

Max. ambient temp. of main body

  150℃

Switch type

  SPST/SPDT



ADVANTAGES:

  • accurate temperature controlling;
  • great contact capacity;
  • wide control range;
  • high reliabilities.



DIMENSION OF MAIN BODY:





SAFETY CERTIFICATE:

C-1:16(2.5) A 250V~C-2:3(0.5) A 250V

C-1:25(2.6) A 277V~C-2:3(0.5) A 277V

VDE,CE,CQC

UL





PRODUCTS RECOMMENDATION:







Exhibition

The 17th international trade fair of household appliance



AWE 2018 - Appliance & Electronics World Expo 2018



Getting more information about high temperature protector and limit switch, please refer to our website: www.thermostat-gb.com

Company Information
 Advantages:

1. With more than 30 years experience of professional thermostat design,

manufacturing and customer service;

2. Have our own bimefal material R&D and production base;

3. With ability for integrating the different resources of the hole group and partners, to innovate and create value for different customers from different sectors and industries;

4. With various production lines and high efficient production capacity.


FAQ



Q1:How can we get a quote?

A: Please offer the specification of the product, such as operating temperature, volt, current, application, quantity etc. Picture or drawing are welcome for our reference.



Q2: What is the MOQ?

A: Normally our MOQ is 1000 pcs. Larger quantity could win lower price.



Q3: What about the lead time?

A: It usually takes about only 7-15 days to produce KSD thermostat, KST thermostat and capillary thermostat would take longer time, which is about 30 days.



Q4:Which payment terms you can accept?

A: T/T, Western Union, L/C



Q5:Guarantee?

A: We offer 3 year guarantee.
